Wireless Communication

• Connectivity

  LTE Cat. M1 / NB-IoT / 2G FallBack

• Operating Frequency

  LTE Cat. M1: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat. NB2: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850,900,1800,1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS & Glonass
  SBAS : WAAS, EGNOS, MASA

• Positioning Accuracy

  +/- 3m CEP (*50%,2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking: -167dBm / Reacquisition: -161dBm / Acquisition: -149dBm

Physical

• Dimensions

  90.2*58*26.2 mm (3.55*2.28*1.03 in)

• Weight

  115 g (4.06 oz)

Hardware (Interface)

• I/O

  14 pin
  - 2 Inputs : Available for Panic button, Door sensor
  - 1 Pin : 1 Digital Input or ADC
  - 1 Pin : 1-Wire for i-button or Temp sensor
  - 2 Pins : RS232
  - 4 Outputs : Siren / Vehicle Blocking / Open drain
  - 4 pins : VCC, GND(2), Ignition
  - 1 Pin : Extnernal Power

• CAN Port

• LED Indicators

  Network, GPS

• Features

  External Power, RS232, 1-wire Interface, Digital Input, DPA (Driving Pattern Analysis), Back-up Battery, Circular/Polygonal Geofencing, Ignition Detection (Ignition/Power/Motion), Compatible with ST20U,ST25T

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Pin connector

• SIM Card Type

  Micro SIM

Battery/Power

• Battery

  Rechargeable 3.7V, 450mA (Ni-MH)

• Power

  Wired, Back-up Battery

• Power Supply

  DC 8 ~ 33 V (* Main power +/- inversion protection) / *External Power : DC 4.5V

• Power Consumption

  Typical: 40 ~ 50 mA (3 min reporting) @12V
  Sleep mode: less than 5mA @12V
  Deep sleep mode: less than 3mA@12V

Environmental

• Dust & Water Resistance

• Operating Temperature

  -30˚C~+85˚C (-22°F~185°F)

• Certifications

  FCC, IC, ANATEL, NOM, IFT

• Region

  USA, Brazil, LATAM
