4G Module

Redefine industrial connectivity with our cutting-edge communication modules, engineered for precision,
durability, and exceptional network integration.

Industrial Grade LTE Cat.1 Module

Items Description
Chipset Qualcomm MDM9207-1 (Cat.1)
Connectivity
  • LTE: B1 / B3 / B5 / B7 / B8
  • WCDMA: B1 / B5 / B8
  • GSM: 900 / 1800MHz
GNSS GPS / GLONASS / BeiDou / Galileo / QZSS
LTE Speed
  • LTE FDD:
    Max 10Mbps (DL) / Max 5Mbps (UL)
  • LTE TDD:
    Max 8.96Mbps (DL) / Max 3.1Mbps (UL)
Memory 1GB NAND + 1GB DDR
Foam Factor LGA, PCIe M.2, PCIe mini
Interface
  • USB 2.0 / HS / UART / I2C / eSIM
  • SGMII / PCM / GPIOs / ADC / RESET
General Feature
  • 3GPP Standards:
    LTE: 3GPP Release 8
    WCDMA: 3GPP Release 9
    GSM: 3GPP R99
  • Miscellaneous:
    Supply Voltage: 3.8V ~4.4V
    Temperature Range: -30°C ~ 85°C
FOTA Support
Dimension 34 x 40 x 3.5 mm
Certification KC / CE / LG U+ / KT
