System on Module

Module with customization expandability by supporting various interfaces based on the excellent
performance Rockchip RK3358M chipset.

System on Module

System on Module circuit board featuring Rockchip RK3358M chipset, 45 x 46 mm compact form factor with 60-pin connectors
Items Description
Chipset

Rockchip RK3358M

  • Quad-core ARM Cortex-A35 CPU
  • SYSTEM SRAM (16KB+8KB)
  • PMU SRAM 8KB
  • 32bits microcontroller core
  • 2D/3D Graphics engine
  • DDR4/DDR3/DDR3L/LPDDR3/LPDDR2
OS Support Android 11
Interface UART / SDIO / LVDS / I2C / I2S / GPIO / ADC
Memory SDRAM 4GB
eMMC eMMC 5.1, 16GB
High Speed Hub Controller USB 2.0
Connector 60Pin x 4
PCB 10-Layer
Power Supply DC 5V
Operating Temperature -40℃ ~ 85℃
Dimension 45 x 46 mm

Benefit

System on Module(SOM) are typically supplied with OS, device drivers, and board support packages, enabling product teams to significantly shorten software development schedules.

Applications Field

  • Smart home icon

    Smart
    Home

  • Telematics icon

    Telematics

  • Industrial equipment icon

    Industrial
    Equipment

  • Medical equipment icon

    Medical
    Equipment

  • Security icon

    Security

  • field6.svg

    Aerospace

  • Mobile device icon

    Mobile
    Device

  • Teaching device icon

    Teaching
    Device
