Wireless Communication

• Connectivity

  LTE Cat. M1 / NB-IoT / 2G FallBack

• Operating Frequency

  LTE Cat. M1 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat NB2 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850/900/1800/1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

  BLE 5.3

• wifi

  WI-FI B/G/N Support 2.4GHz only

GNSS

• Receiver Type

  GPS, GLONASS, BeiDou, Galileo
  SBAS : WAAS, EGNOS, MASA, GAGAN

• Positioning Accuracy

  +/- 1.5m CEP (*50%,2D RMS, -130dBm, >6 Sats.)

• Update Rate

  18Hz (Single GNSS) / 5Hz (4 Concurrent GNSS)

• Cold Start (TTFF)

  < 24s

• Warm Start (TTFF)

  < 2s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking: -167dBm / Reacquisition: -161dBm / Acquisition: -149dBm

Physical

• Dimensions

  62*258*61 mm (2.44*10.16*2.40 in)

• Weight

  714 g (25.19 oz)

Hardware (Interface)

• I/O

  3 Pins : Ground, Power, 1-wire

• CAN Port

• LED Indicators

  Network, GPS, Power

• Features

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  External Magnet (Power Pawn)

• SIM Card Type

  Micro SIM

Battery/Power

• Battery

  Primary Battery 3.6V, 57,000mAh

• Power

  Up to 10 Years @ 1 report per day (power saving mode)

• Power Supply

  12V DC

• Power Consumption

  Active mode : 40~60mA
  Sleep mode (Cell On-GNSS Off) : ~15uA
  Deep sleep mode (Cell Off-GNSS Off) : <10uA

Environmental

• Dust & Water Resistance

  IP67

• Operating Temperature

  -30°C~+85°C (-22°F~+185°F)

• Certifications

  FCC, PTCRB, IC, CE, AT&T, T-Mobile, Verizon, US Cellular, NOM, IFT

• Region

  USA, LATAM, EU
