Wireless Communication

• Connectivity

  LTE Cat. M1 / NB2-IoT / 2G FallBack

• Operating Frequency

  Cat M1 : B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85
  Cat NB2 : B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66/B71/B85
  2G : 850/900/1800/1900MHz
  * BG95_M1 is not surpport to 2G

• Transmission Protocol

  TCP / UDP

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS & GLONASS, Galileo, Beidou, QZSS
  GPS & Glonass
  SBAS : WAAS, EGNOS, MASA

• Positioning Accuracy

  +/- 2.5m (*50%, 2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking: -167dBm / Reacquisition: -161dBm / Acquisition: -149dBm

Physical

• Dimensions

  92.5*39.5*25.5 mm (3.64*1.56*1.00 in)

• Weight

  150g (5.29oz)

Hardware (Interface)

• I/O

• CAN Port

• LED Indicators

  On/Off, GPS Status, Cellular Status

• Features

  Data Storage: up to 1,000 locations, in case of transmission failure or cost savings.
  Reports: Cyclic location reporting with interval adjustable, either at pre-set time interval or making possible only when command comes.

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Power on/off Button, Magnet & Screw mounting option

• SIM Card Type

  Micro SIM

Battery/Power

• Battery

  Primary Battery 3.6V, 8,000mAh

• Power

  Battery-Operated

• Power Supply

• Power Consumption

  Active : ~ 220mA
  Deep sleep mode : < 15uA

Environmental

• Dust & Water Resistance

  IP67

• Operating Temperature

  -20°C~+80°C (-4°F~176°F)

• Certifications

  FCC, PTCRB, CE, T-mobile, US Cellular, NOM

• Region

  USA, LATAM, EU

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
