Wireless Communication

• Connectivity

  LTE Cat. M1/ NB2-IoT/ 2G FallBack

• Operating Frequency

  LTE Cat. M1: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat. NB2: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850,900,1800,1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS, GLONASS
  SBAS : WAAS, EGNOS, MASA

• Positioning Accuracy

  +/- 3m CEP (50%,2D RMS, -130dBm, >6 Sats.)

• Update Rate

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking -167dBm / Acquisition -149dBm

Physical

• Dimensions

  97.4(W) x 130(L) x 37.5(T) mm

• Weight

  ST4335: 330g, ST4335+: 358g

Hardware (Interface)

• I/O

  15 Wired
  - 1pin White/blue: Ext power (DC 4.5V) optional
  - 2pin White/gray: Output4 optional
  - 3pin White/yellow: Output3 optional
  - 4pin Brown: Output2 Standard
  - 5pin Orange: Output1 Standard
  - 6pin Purple: RS232-Rx optional
  - 7pin Black: Ground Standard
  - 8pin Red: VCC (DC12/24) Standard
  - 9pin White: Input1 Standard
  - 10pin yellow: Input2 Standard
  - 11pin Green: Input3 Standard
  - 12pin White/black: 1-wire Standard
  - 13pin White/brown: Input4/ADC Standard
  - 14pin Gray: RS232-Tx optional
  - 15pin blue: Ignition Standard

• CAN Port

• LED Indicators

  Network, GPS

• Features

  RS232, Digital Input, Jamming Detection(*Optional), DPA (Dirving Pattern Analysis),Back-up Battery, 1-wire Interface, Ignition Detection (Ignition/Power/Motion)
  - Geo-fencing: Circular up to 250 points/Polygon up to 30 points
  - Data Storage: up to 10,000 locations, in the event of a transmission failure,
  minimizing data plan expense.
  -Security Alarm : Alert for Geo-fencing, Low main battery, backup battery’s defect, GPS defect, Over speed, Specific sensors triggered and Vehicle crash. Parking lock and Cut off main power.

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Power on/off Button

• SIM Card Type

  Micro SIM

Battery/Power

• Battery

  Rechargeable 7.8 Ah (Li-ion) / 3.7V

• Power

  Wired, Battery Operated Tracker

• Power Supply

  DC 8 ~ 38 V (* Main power +/- inversion protection)

• Power Consumption

  Typical : 40mA ~ 60mA
  Sleep mode : < 5mA
  Deep sleep mode : ~ 2mA

Environmental

• Dust & Water Resistance

  IP67

• Operating Temperature

  -30°C ~ +80°C (with vehicle power) / -20°C ~ +60°C (with back-up battery)

• Certifications

  FCC, PTCRB, CE, AT&T, T-Mobile, Verizon, US cellular, NOM

• Region

  USA, LATAM, EU
