Wireless Communication

• Connectivity

  LTE Cat. M1 / NB-IoT / 2G FallBack

• Operating Frequency

  LTE Cat. M1: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat. NB2: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850,900,1800,1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

  BLE 5.3

• wifi

GNSS

• Receiver Type

  GPS + Galileo Concurrent
  GPS, QZSS, GLONASS, Beidou, Galileo
  SBAS : WAAS, EGNOS, MASA, GAGAN
  AGPS (Optional)

• Positioning Accuracy

  +/- 1.5m CEP -50%

• Update Rate

  18Hz (Single GNSS) / 5Hz (4 Concurrent GNSS)

• Cold Start (TTFF)

  < 24s

• Warm Start (TTFF)

  < 2s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking: -167dBm / Reacquisition: -161dBm / Acquisition: -148dBm

Physical

• Dimensions

  62.28*113.5*30 mm (2.45*4.47*1.18 in)

• Weight

  193.6 g (6.83 oz)

Hardware (Interface)

• I/O

• CAN Port

• LED Indicators

  Device Status ( Device Power On/Off, Battery Level (1~4 level) ) GNSS, Modem

• Features

  Tamper Detection (Light sensor)
  External Charging via cable (SA15)

• Motion Sensor

  6-Axis Accelerometer

• User Interface

  External Power Connector

• SIM Card Type

  Nano SIM

Battery/Power

• Battery

  Rechargeable 3.7V, 5,900mAh

• Power

  Battery-Operated

• Power Supply

  Please use the SA15 (charging cable) or a 5V power source.

• Power Consumption

  Active mode : 40~50mA (Interval Time 10min)
  Deep sleep mode :
  - less than 55uA (Motion Disable_suspend mode)
  - less than 105uA (Motion Enable_Low pwr mode)

Environmental

• Dust & Water Resistance

  IP67

• Operating Temperature

  -10°C~+60°C (14°F~140°F)

• Certifications

  FCC, PTCRB, AT&T, (VZW,TMO Pending)

• Region

  USA

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
