Wireless Communication

• Connectivity

  LTE Cat. M1 / NB-IoT / 2G Fallback

• Operating Frequency

  LTE : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B71, B85
  GSM : B2 (900MHz), B3 (1800MHz), B5 (850MHz), B8 (900MHz)

• Transmission Protocol

  TCP / UDP

• Bluetooth

  BLE 5.3

• wifi

GNSS

• Receiver Type

  GPS, GLONASS, Galileo, BeiDou

• Positioning Accuracy

  +/- 2m CEP (50%, 2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking: -167dBm / Reacquisition: -161dBm / Acquisition: -149dBm

Physical

• Dimensions

  59*50*24 mm (2.32*1.97*0.94 in)

• Weight

  55 g (1.94 oz)

Hardware (Interface)

• I/O

• CAN Port

  OBDII 16pin connector J1962
  Pin 2/10 : J1850(PWM or VPW) protocols
  Pin 7 : ISO 9141-2 & ISO 14230, K-Line
  Pin 15, L-Line
  Pin 6/14 ISO 15765-4 Protocols (CAN)
  *OBD 2 standard connector J1962
  Heavy Duty truck Data: J1939 ELD, FMS support

• LED Indicators

  Network, GPS

• Features

  Dead Reckoning
  J1939 ELD & FMS support
  Back-up Battery

• Motion Sensor

  Built-in 3-axis accelerometer, 3-axis gyroscope

• User Interface

• SIM Card Type

  Nano SIM

Battery/Power

• Battery

  Rechargeable 3.7V, 90mAh (Li-ion)

• Power

  OBD-II Port

• Power Supply

  DC 8 V ~ 28 V (* Main power +/- inversion protection.)

• Power Consumption

  Active mode: 120-130mA @12V
  Sleep mode: < 5mA @12V
  Deep sleep mode: < 4mA@12V

Environmental

• Dust & Water Resistance

• Operating Temperature

  -30˚C~+85˚C (-22°F~185°F)

• Certifications

  Regulatory: FCC, IC, CE, NOM, ANATEL | Industry/Carrrier: PTCRB, AT&T, Verizon, T-Mobile

• Region

  USA, Brazil, LATAM, EU

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
